description of the product
WOOD-ALUMINIUM
STRUCTURE
composite window, wood-aluminium; the leaf and frame thickness 68 mm, frame with cladding 80 mm, additional aluminium
leaf fixed on wooden leaf, glazing bead R=3 mm
MATERIAL
glued laminated pine wood, optionally oak
FINISH
water soluble covering paints or transparent paints, a three-layer covering system, a four-layer transparent system;
powder painted aluminium, the RAL basic colours RAL 9016, 9010, 9007, 9006, 9005, 8019, 8017, 8007, 8001, 7042, 7035, 7016, 6005, 5010, 3004, 1013 the other colours of the RAL palette are available at extra charge
STANDARD OF CONSTRUCTION
- Double glazed window 4/16Ar/4/ Ug=1,0 W/m2K with warm edge spacer bars, 4 mm toughened glass in aluminium leaf, optionally thermopanel with aluminium sheet on the outside of the balcony windows
- hinge caps
- Roto NX peripheral hardware with microventilation function (for rectangular Tilt&Turn windows) with three-level adjustment, with anti-theft protection, handle misplacement block
- three profile seals available in white or brown
- additional seal between the frame cladding and the leaf cladding
- aluminium cladding on the outside
- handles
ADDITIONAL ACCESSORIES
- glazing units
- colours of louvre slats
- fitting accessories
- muntins: inter-pane bars and structural bars
- air inlets
PARAMETERS
- thermal transmittance*: 1,0 W/(m2K)
- water tightness: E1050
- resistance to wind load: C2
- air permeability: 4
(*) The provided values of the thermal and acoustic insulation apply to the reference window of the dimensions of 1,23 x 1,48 m
