description of the product

C-30

CONSTRUCTION OF THE WING:

  • Interior entrance door leading from corridors or staircases to e.g. flats in multi-family buildings or rooms in public utility buildings.
    Door leaf constructed of a wooden rail and stile set topped with two HDF boards. The in-fill is a special POL-SKONE structure.
    The leaf thickness is 56 mm.

STANDARD EQUIPMENT (INCLUDED IN THE PRICE):

  • fixed pine wood door frame
  • handle and plate set with a cylinder protection, class 6 cylinders (nickel-satin)
  • strip type mortise five point bolt lock, spacing: 72 mm, colour: silver
  • adjustable screw-in pivot hinges (“80” - “90” – 3 pcs; ”100” –4 pcs)
  • levering protection bolts - 5 pcs
  • oaken threshold with a height of 20 mm

DOOR FRAMES:

  • rebated SYSTEM: fixed pine wood door frame, one-sidedly adjustable door frame

ADDITIONAL (available at an extra charge):

  • SILKSTONE CPL surface
  • adjustable door frame
  • GARDA rosette in the colour of silver
  • class 3 GARDA handle in the colour of silver
  • complete set of class 6 cylinders in the colour of silver
  • viewer
  • size 1112 x 2175 mm
  • GARDA handle in the colour of black
  • GARDA upper rose in the colour of black
  • GARDA cylinder in the colour of black
  • edges in other colours are available - upon consultation with the Sales Department

DIMENSIONS:

  • standard: 1012 x 2075 mm
    optional: 880x1950 mm; 880x2000 mm; 880x2075 mm; 980x1950 mm; 980x2000 mm; 980x2075 mm; 1012x1950 mm; 1012x2000 mm
  • 90 Plus width - 1032x2075 mm (allowing to get the clear opening of min. 900 mm when the door leaf is opened at an angle of 90°)

ADDITIONAL INFORMATION:

  • burglary resistance
    POL-SKONE C-30 – class RC3 according to PN-EN 1627:2012
    – class C according to PN-B-92270:1990
  • smoke control: class Sa, S200
  • fire resistance: class EI230
  • acoustic insulation: D1-35, D2-35, Rw=37 dB
  • 4 mechanical class according to PN-EN 1192:2001
  • ITB technical approval: ITB–KOT-2018/0713 edition 1

NOTE! The door should be provided with an automatic door closer conforming to the requirements of the PN-EN 1154:1999/
A1:2004/AC:2010 standards and door handles conforming to the requirements of the PN-EN 1906:2012 standard to meet the fire resistance conditions. To ensure that the door meets the antiburglar specifications, door handles should comply at least with the class 3 anti-burglar resistance rating whereas door lock cylinders should comply at least with the class 4 key-related resistance rating and min. class 1 attack resistance rating according to the PN-EN 1303:2007+AC:2008 standard.
