description of the product

SYSTEM

  • rebated system

SPECIFICATION

  • Dedicated for the LUMEN glass pane.
  • Door frame made of 1.5 mm thick sheet metal.
  • Powder-coated door frame. Standard colours: white (RAL 9016), white (RAL 9003), grey (RAL 7047), brown (RAL 8014), beige (RAL 1001), graphite (RAL 7024), black (RAL 9005). Other RAL colours are available at an extra charge - upon consultation with the Sales Department (except the metallic and pearl ones)

EXTRA CHARGES:

  • compatible with the electric door strike
  • electric averse action door strike JiS typ 1710-12 AC (including a catch plate)
  • electric averse action door strike BIRA HARTE XS narrow XS12U 12V AC/DC (including a catch plate)
  • electric averse action door strike with switch BIRA HARTE XS narrow XS12UW 12V AC/DC (including a catch plate)
  • electric reverse action door strike BIRA HARTE XS narrow XS12R 12V DC (including a catch plate)

DIMENSIONS

single leaf door
WIDTH
typ
So
Sd
Sc
Ss
"60"
681
671
697
617
"70"
781
771
797
717
"80"
881
871
897
817
"90"
981
971
997
917
HEIGHT

Ho
Hd
Hc
Hs

2060
2055
2068
2017

Ss - door leaf width
Sd – door frame external width
So - installation hole width
Sc – total door frame width
Hs - door leaf height
Hd – door frame external height
Ho - installation hole height
Hc - total door frame height



Select a model

fixed lumen

COLOURS - METAL

RAL 9016

RAL 9005

RAL 9003

RAL 8014

RAL 7047

RAL 7024

RAL 1001

System

NON-REBATED SYSTEM

Surface

PAINTED

GROSS PRICE FROM

396,06 PLN
