FIRE-RATED EI60 PLUS HALSPAN SYSTEM

Door fire-rated rebated EI30 Plus Halspan system with a metal frame equipped with anti-panic fittings PHA 2000 or PHA 2500 and hinges EXACTA 495 16 mm conforming to the requirements of the PN-EN 1125:2009 standard in terms of ability for release and can be used on emergency routes and exits.

CONSTRUCTION OF THE WING:

Rebated system door leaf. Door frame wooden or metal (fixed or adjustable). The door leaf structure consists of a multilayer
chipboard with softwood label, topped with HDF boards on both sides. The rated door leaf thickness is: 60 mm.

PARAMETERS:

• Fire resistance EI60
• acoustic insulation
• single leaf: class D1 – 30, D2 – 25, class Rw=32 dB
• double leaf: class D1 – 25, D2 – 25, class Rw=32 dB
• Smoke protection class Sa, S200 (option)
• 3 mechanical class acc. to PN-EN 1192:2001
• National Technical Assessment ITB-KOT-2018/0407 edition 1
• National Certificate of Constancy of Performance No. 020-UWB-2695/W



GLAZING:

Transparent glass with the EI30 fire resistance. Pine wood frame painted, veneered or covered with a foil matching the colour of the door leaf. Available glazing type of porthole with a steel frame Ø320 mm (on the outside of the frame).

STANDARD EQUIPMENT (INCLUDED IN THE PRICE):
(door with a wooden or metal door frame )

• 3 or 4 pivot hinges adjustable in 3 planes by OTLAV
• mortise lock with a patent insert
• drop down seal

DOOR FRAME:

• painted, veneered, covered with CPL 0.15 mm laminate or foil matching the colour of the door leaf.
• Fixed pine wood frame optionally provided with a masking strips or a shoe moulding.
• Adjustable wooden frame with widening panels, architraves and a masking strip
• Fixed metal door frame made of 1.5 mm thick steel sheet available in standard powder coatings in the following colours: white (RAL 9016 and RAL 9003), grey (RAL 7047), brown (RAL 8014), beige (RAL 1001), graphite (RAL 7024), black(RAL 9005).
• Adjustable metal made of 1.5 mm thick steel sheet available in standard powder coatings in the following colours: white (RAL 9016 and RAL 9003), grey (RAL 7047), brown (RAL 8014), beige (RAL 1001), graphite (RAL 7024), black(RAL 9005).
• Metal door frames painted in non-standard RAL or NCS colours are available (after consultation with the Sales Department).
• Door frame consists of the main part and an architraves inserted into the main part.

ADDITIONAL EQUIPMENT (available at an extra charge):

• aluminum decors, decorations, surface-mounted door closer or concealed, anti-panic locks, anti-panic levers, electric door strike, electromagnetic locks, reed switch
• The possibility of preparation in the door leaf milling for the lock (electronic) hotel (after consultation with the Sales Department).

DOOR DIMENSIONS:

• Fixed door frame wooden or adjustable:
  Rebated system
  Single leaf door:
  max. width „110” – 1212 mm, max. height 2500 mm
  Version 90 Plus (allows to get the clear opening of min. 900 mm when the door leaf is opened at an angle of 90°) 1032x2075 mm Double leaf door full:
  max. width „110+110” – 2352 mm, max. height 2500 mm
  Double leaf door glazed:
  max. width „100+100” – 2152 mm, max. height 2350 mm
• Fixed metal door frame:
  Rebated system
  Single leaf door:
  max. width „110” – 1204 mm, max. height 2271 mm
  Version 90 Plus (allows to get the clear opening of min. 900 mm when the door leaf is opened at an angle of 90°) 1024x2071 mm Double leaf door full:
  max. width „110+110” – 2342 mm, max. height 2271 mm
  Double leaf door glazed:
  max. width „100+100” – 2142 mm, max. height 2271 mm
• Adjustable metal door frame:
  Rebated system
  Single leaf door:
  max. width „110” – 1224 mm, max. height 2281 mm
  Version 90 Plus (allows to get the clear opening of min. 900 mm when the door leaf is opened at an angle of 90°) 1044x2081 mm Double leaf door full:
  max. width „110+110” – 2362 mm, max. height 2281 mm
  Double leaf door glazed:
  max. width „100+100” – 2162 mm, max. height 2281 mm

ADDITIONAL INFORMATION:

NOTE! In order to meet the fire resistance conditions, the door should be provided with the automatic door closer conforming to the requirements of the PN-EN 1154:1999/A1:2004/AC:2010 standard, door handles conforming to the requirements of the PN-EN 1906:2012 standard (min. class B to the extent related to fire resistance) and drum cylinders conforming to the requirements of the PN-EN 1303:2007+AC:2008 standards (class 1 to the extent related to fire resistance).
